The truck can be equipped with appropriate factory-fitted components. The primary requirement from customers is on load capacity, hence the adoption of 6 axles.
- U-Shaped Cargo Box: Inner dimensions 11.2m × 2.4m × 1.67m, yellow in color. Overall external length not exceeding 12 meters.
- Axle Configuration: 6 axles in total. The front 3 axles are equipped with liftable air suspension; the rear 3 axles adopt 13-ton Guangdong Fuwa axles.
- Main Beam: 500mm in height. Upper and lower flange plates: 14mm/16mm thick; vertical web plates: (6+6)mm thick; cargo box floor: 10mm thick; cargo box side plates: 6mm thick.
- Tires: Front 3 axles fitted with 6 pcs of 385 single tires; rear 3 axles fitted with 12 pcs of 12R22.5 tubeless tires.
- Lifting Cylinder: Yangzhou Hyva FC214-5 hydraulic cylinder, with a lifting capacity of 80 tons.
- Additional Structure: Thickened leaf springs for the rear 3 axles; 6-channel frame structure with stabilizing brackets; "field"-shaped reinforcement grid (inside the cargo box); wax spraying treatment (for rust prevention)
